| Place of Origin: | China |
|---|---|
| Brand Name: | HBS |
| Certification: | ISO,CE |
| Model Number: | HSW-01 |
| Minimum Order Quantity: | ≥1Set |
| Price: | USD1000-30000 |
| Packaging Details: | Plywood packed with export sea standard |
| Delivery Time: | 15-20Days |
| Payment Terms: | T/T, L/C, D/A, D/P |
| Control System: | PLC | Material: | Brass |
|---|---|---|---|
| Name: | Brass Rod Peeling Machine | Operation Mode: | Automatic |
| Power: | 19.6KW | Processing Efficiency: | 99.9% |
| Processing Range: | φ9-70mm | Speed: | 25.8m/min |
| Voltage: | 3800V | Weight: | 2800KG |
| Highlight: | Brass Rod Peeling Machine 18.5kw,Soild Brass Rod Peeling Machine,Brass Rod Peeling Machine 25.8m/min |
||
Copper Rod Surface Peeling For Soild Rod Hollow Rod Peeling
Main Technical Parameters
| SL | SPECIFICATION | |
| 1 | Max Peeling Length | 4.2m |
| 2 | Max Peeling Size(Round rod) | φ9-φ70mm |
| 3 | Max Peeling Size(Hex rod) | φ9-φ60mm |
| 4 | Max Peeling Size(Square rod) | φ9-φ60mm |
| 5 | Max System Pressure | 200kg/m³ |
| 6 | Large Chain Speed | 25.38m/min |
| 7 | Main Motor Power | 18.5kw |
| 8 | Hydraulic Cylinder Size | 45*85*510mm |
| 9 | Oil Deposited | 125L |
| 10 | New Weight | 2800kg |
| 11 | Dimension(L*W*H) | 9600*1300*1300mm |
Description&Characteristic
copper rod surface peeling machine is a specialized industrial equipment used to remove the outer layer or surface of copper rods. The process of peeling involves removing the oxidized or contaminated surface layer to expose the clean and fresh copper underneath.
The machine typically consists of a rotating drum or wheel that holds the copper rod. The drum is equipped with cutting blades or abrasive materials that scrape or grind the surface of the rod as it rotates. The peeling action removes the unwanted surface layer, leaving behind a smooth and clean copper surface.
The machine is designed to handle different sizes and lengths of copper rods. It can be operated manually or automated, depending on the specific model. Some advanced machines may also include features such as adjustable peeling depth, speed control, and safety mechanisms.
