| Place of Origin: | CHINA |
|---|---|
| Brand Name: | HBS |
| Certification: | CE,ISO |
| Model Number: | GYT-500 |
| Minimum Order Quantity: | ≥1Set |
| Price: | USD10000-80000 |
| Packaging Details: | Plywood packed with export standard |
| Delivery Time: | 15-20days after deposit |
| Payment Terms: | TT,L/C,D/A,D/P |
| Supply Ability: | 50Sets per month |
| Cooling Method: | Water Cooling | Material: | Brass |
|---|---|---|---|
| Rod Diameter: | Customizable | Rod Length: | Customizable |
| Energy Efficiency: | High | Casting Method: | Continuous Casting |
| Capacity: | Customizable | Control System: | PLC |
| Name: | Brass Rod Continuous Casting Machine | ||
| Highlight: | 380V Copper Rod Continuous Casting Machine,Brass Ingot Continuous Casting Machine |
||
Most Popular Product In Asia Brass Ingot Continuous Casting Machine
The Brass Rod Continuous Casting Machine is a state-of-the-art equipment designed for efficient and continuous casting of brass rods. It is a part of the larger brass rod continuous casting plant, which also includes a brass tube drawing machine and a brass bar continuous caster. This machine is powered by electricity and is highly energy efficient, making it a cost-effective and environmentally friendly option for brass rod production.
The Brass Rod Continuous Casting Machine runs on electricity, making it easy to operate and maintain. This also reduces the use of fossil fuels, making it a more sustainable option for brass rod production.
This machine is designed with energy efficiency in mind. It uses advanced technology and processes to minimize energy consumption, resulting in lower production costs and a smaller carbon footprint.
The Brass Rod Continuous Casting Machine is equipped with a Programmable Logic Controller (PLC) system, which allows for precise and automated control of the casting process. This ensures consistent and high-quality output, while also reducing the need for manual intervention.
As the name suggests, the Brass Rod Continuous Casting Machine uses the continuous casting method, which involves the constant pouring of molten brass into a mold to produce long, continuous rods. This method results in a more uniform and defect-free product compared to traditional casting methods.
The Brass Rod Continuous Casting Machine is specifically designed for casting brass rods. Brass, a metal alloy made of copper and zinc, is a popular choice for various industrial applications due to its strength, durability, and corrosion resistance.
Overall, the Brass Rod Continuous Casting Machine is a reliable, efficient, and cost-effective solution for producing high-quality brass rods. Its advanced technology, energy efficiency, and precise control system make it a valuable addition to any brass rod production facility.
| SL | SPECIFICATION | |
| 1 | Melting Rate | 500kg/h |
| 2 | Chamber Capacity | 2 |
| 3 | Temperature Rating | 1000-1100℃ |
| 4 | Total Rated Capacity Of Melting Furance | 3000kg |
| 5 | Total Rated Capacity Of Holding Furance | 40000kg |
| 6 | Voltage | 380V,50HZ |
| 7 | Cos After Compensation | 0.95-1 |
| 8 | Cooling Water Consumption | 10m³/h |
| 9 | Water Pressure | 0.3-0.4Mpa |
| 10 | Total Power | 250Kw |
Thank you for choosing our Brass Rod Continuous Casting Machine. We are committed to providing you with the best technical support and service to ensure the smooth operation and maintenance of your machine.
Our team of highly skilled technicians is available to provide you with technical support for any issues or questions you may have regarding the operation of your Brass Rod Continuous Casting Machine. We offer remote support via phone or online communication, as well as on-site support if needed.
Our technical support services include:
We understand the importance of keeping your Brass Rod Continuous Casting Machine running smoothly and efficiently. That's why we offer comprehensive service plans to meet your specific needs.
Our service plans include:
Our goal is to ensure the long-term performance and reliability of your Brass Rod Continuous Casting Machine, and we will work tirelessly to exceed your expectations.
1.COULD YOU ARRANGE THE ENGINEER FOR INSTALLATION AND COMMISSIONING?
A:Obviously yes,but the buyer pay the charges.
2.HOW TO CHOOSE ROD MAKING MACHINE?
A:It depends on your daily/monthly production required.(Contact us for the details)
3.DO YOU PROVIDE ANY SPARE PARTS WITH THE MACHINE?
A:Yes,we will provide some common parts for you according to our packing list(cotact us for packing list)
4.WHAT IS THE DELIVERY PERIOD AFTER PLACING THE ORDER?
A:Normally 15-20days after deposit..
5.WHAT IS THE WARRANTY PERIOD AND AFTER-SERVICE FOR YOUR MACHINE?
A:1 year warranty for components and life-long technical supports(details depends on the warranty rules)
