| Place of Origin: | CHINA |
|---|---|
| Brand Name: | HBS |
| Certification: | CE,ISO |
| Model Number: | 400B |
| Minimum Order Quantity: | ≥1Set |
| Price: | USD1000-5000 |
| Packaging Details: | Plywood packed with export sea standard |
| Delivery Time: | 15-20 Days |
| Payment Terms: | T/T,L/C.D/A.D/P |
| Supply Ability: | 50Sets per month |
| Casting Method: | Hot Box | Air Pressure: | 0.5-0.8MPa |
|---|---|---|---|
| Type: | Automatic | Warranty: | 1Year |
| Control System: | PLC | Condition: | New |
| Power: | 380V/50Hz | Name: | Sand Core Shooting Machine |
| Highlight: | plc control sand core machine,380v sand core machine |
||
HBS 400B Sand Core Shooting Machine is an automatic, PLC-controlled system that uses the hot box casting method for sand core manufacturing. It features an air pressure range of 0.5-0.8 MPa and is brand new. It is an essential sand core forming machine that can inject sand core efficiently and accurately. It is also a reliable sand core injector that can help you achieve superior sand core manufacturing results.
| SL | SPECIFICATION | |
| 1 | Max Sand Core Weight | 3.2kg*2 |
| 2 | Max Mold Size | 340*450*200(mm) |
| 3 | Max Distance Between Nozzies | 270mm |
| 4 | Max Stroke Of Vertical Clamping | ≤300mm |
| 5 | Sand Box L-R Distance | 150mm |
| 6 | Power | 7.5kw |
| 7 | Net Weight | 800kg |
| 8 | Dimension | 1420*680*1700(mm) |
Packing and Shipping
